DT Swiss 180 Front Hub 20H with Ceramic Bearings
DT Swiss 180 Ceramic Cartridge Front Hub
DT Swiss pushed the limits of their technologies when designing the 180 carbon ceramic hub line. No details were overlooked in optimizing weight or rolling resistance. All 180 hubs use a composite hubshell design that combines extensively machined aluminum flanges with a carbon fiber center section. DT Swiss SINC ceramic bearings are factory installed to minimize rolling resistance while maintaining the reliability DT Swiss is know for.
Technical Information:
Weight: 107g +/- 5%
Hole Count: 20 ONLY
Axles Standard: 15x100mm TA, 100mm QR
Axles Optional: 12x100mm TA, 9x100mm TA (Sold separately)
Bearings: 2 x 6903/18 DT SINC Ceramic
Hub shell material: Aluminum flanges with carbon fiber center section
- Ideal use: High performance off road racing, road disc, CX and training.
For wheel building dimensions please visit the DT Swiss spoke
The 180 Center Lock hub is convertible between axle options using
Accessories Included:
Adapter IS 6-Bolt 15mm CL
100 Thru axle 15 mm (Pre-installed)
FW Adapt Kit 100/QR for 180 DB
FW Adapt Kit 100/12 for 180 DB
| Dimensions | 6x6x6 |
|---|
